9.5m*2.55m*3.1m Long-distance Towing Trailer 40T Load Q345B
Bearing Detail
| Dimensions(LxWxH) | 9500*2550*3100 mm The height of the beam is 420mm,upper plate is 12mm*140,down plate is 12*140mm,middle plate is 6mm |
| Body length | 9.5M |
| Body width | 2.55M |
| Body height | 3.1M |
| Design load | 40T |
| Vehicle weight | 6.9 tons |
| Number of axle | 3 |
| Leaf spring | Leaf spring 10pcs*90*13mm |
| Number of wheels | 12 |
| ABS system | YES |
| Turntable | Diameter is 1100mm |
| Traction hook | DN50 |
| The material of Main beam | Q345 |
| Platform plate | 3mm Diamond Plate |
| Braking system | WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
| Lights | LED 8 side lights and 2 rear lights 2 width lamp |
| Painting | Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint wax spray |
| Marking | According to the requirement of the buyer |
| Side Guard | According to the requirement of the buyer |
| Accessories | One standard tool box,one spare tire carrier,one crank,one shaft headwrench,four side light,two rear light |
| Water tank | The size can be choose freely. |
Performance characteristics of trailers
Powerful power system
Usually equipped with a high-torque engine (mainly diesel engine) to ensure traction capacity at low speed and high load.
Some heavy-duty trailers use multi-axle drive or all-wheel drive to enhance escape and climbing performance.
High load-bearing and torsion-resistant structure
The frame is made of high-strength steel or reinforced design to resist torsional stress during towing.
Equipped with heavy-duty suspension system (such as leaf spring or air suspension) to adapt to different loads.
Professional towing device
Standard towing hook, winch, hydraulic arm, etc., some support automatic connection (such as fifth wheel coupler for semi-trailer).
The electronic control system can adjust the traction distribution to prevent slipping or overload.
Safety and stability
Integrated ABS, ESP (electronic stability program) and anti-rollover system, especially suitable for long-distance towing.
Lights and warning signs comply with regulations to ensure visibility at night or in bad weather.
Multifunctional adaptability
It can be equipped with flatbeds, cargo boxes, booms and other modules to adapt to different scenarios (such as accident rescue, logistics transportation).
Main application areas of trailers
Road rescue and accident handling
Towing faulty vehicles (such as tow trucks), accident vehicles or illegally parked vehicles.
Rescue trailers equipped with hydraulic platforms or booms can handle complex situations such as rollovers and cliff falls.
Logistics and freight
Semi-trailer tractors are used for long-distance transportation of containers, bulk cargo, etc. to improve logistics efficiency.
Port terminals use heavy-duty trailers to transfer containers or large equipment.
Special operations
＊Engineering field: Towing construction machinery such as excavators and road rollers.
＊Aviation field: Aircraft tractors (non-powered or electric) are used to move aircraft within airports.
＊Military use: Towing artillery, radar equipment or armored vehicles.
Agriculture and industry
Agricultural trailers transport crops or agricultural machinery, such as trailers towed by tractors.
In-factory trailers carry heavy parts (such as wind turbine blades).
Leisure and civil
RV trailers (Travel Trailer) or yacht trailers to meet outdoor travel needs.
Family SUVs tow small trailers (such as motorcycle trailers, horse transporters).
